48V Lithium Ion Battery Packs

Built Around Your Equipment’s Electrical and Mechanical Requirements

A battery pack needs to work with more than a voltage rating. Charging voltage, available space, connections and control electronics all affect how it fits into an OEM product. YATTOX provides engineering and assembly support for 48V lithium ion battery packs, including cell arrangements, BMS integration, wiring and pack structures tailored to defined equipment requirements.

Explore 48V Battery Options

Home > Products > Lithium Battery Pack > 48V Battery Packs

Explore Battery Options ↓

48V Li-ion Battery Pack Configurations

A 48V Li-ion battery pack can be built with different series-parallel arrangements to accommodate the required capacity and installation layout. In a typical 13S design, thirteen cell groups establish the pack voltage. Adding cells in parallel increases capacity, although the final discharge capability also depends on the selected cells, interconnections and protection system.

For OEM projects, both 18650 and 21700 cylindrical cells can be considered.

48V Battery Capacity Options: 10Ah to 30Ah

Capacity selection affects the amount of energy available, the number of cells required and the physical size of the pack.

A 48V 20Ah lithium ion battery pack, for example, may be suitable for equipment requiring more energy than a smaller 10Ah configuration. A 48V 30Ah lithium ion battery pack provides additional nominal capacity, but also requires careful consideration of pack dimensions, weight and mounting.

The following arrangements illustrate common 13S design possibilities.

Reference 13S Battery Configurations

These figures describe reference cell arrangements calculated using 3.7V nominal cells. Actual electrical ratings, physical dimensions and production availability depend on the selected components and final pack specification.

Cell Type	Cell Arrangement	Example Cell Capacity	Pack Capacity	Nominal Voltage	Nominal Energy
18650	13S4P	2,500mAh	10Ah	48.1V	481Wh
18650	13S4P	3,000mAh	12Ah	48.1V	577.2Wh
21700	13S4P	5,000mAh	20Ah	48.1V	962Wh
21700	13S6P	5,000mAh	30Ah	48.1V	1,443Wh

Choosing Between 18650 and 21700 Cells

A 48V 18650 battery pack offers a range of possible cell arrangements for different equipment layouts. 21700 cells have larger dimensions and may offer higher capacity per cell, depending on the model. This can change the number of parallel cells required to reach the intended capacity.

The better option is not determined by cell size alone. Current rating, cell availability, total pack weight, available space and assembly requirements all influence the selection.

18650 and 21700 cylindrical cells for 48V battery pack design — Cylindrical cell module assembly concept for 13S 48V pack design

13S Battery Voltage: What Must Match?

A device described as 48V does not necessarily operate at exactly 48V throughout its battery cycle.

For a conventional 13S lithium-ion arrangement using cells rated at 3.7V nominal and 4.2V maximum charging voltage, the pack is rated at 48.1V nominal and reaches 54.6V when fully charged.

48.1V

13S Li-ion nominal

54.6V

13S Li-ion full charge

51.2V

16S LiFePO4 nominal

58.4V

16S LiFePO4 full charge

Comparing 48V-Class Battery Chemistries

Both battery types may appear in equipment described as 48V, but their charging voltages and operating characteristics are different.

Parameter	Conventional 13S Li-ion	Typical 16S LiFePO4
Cell arrangement	13S	16S
Nominal cell voltage	3.7V	3.2V
Nominal pack voltage	48.1V	51.2V
Typical full-charge voltage	54.6V	58.4V
Charging specification	Based on 13S Li-ion cells	Based on 16S LiFePO4 cells

This page focuses on conventional lithium-ion configurations. LiFePO4 battery requirements should be reviewed separately rather than treated as an interchangeable specification.

Check the Charger and Input Voltage Range

A 54.6V charging limit is common for 13S lithium-ion packs using 4.2V-charge cells. The charger must also use an appropriate charging profile and current limit. The equipment must tolerate the battery voltage at full charge as well as during discharge.

Before replacing an existing pack, confirm the original battery chemistry, controller voltage range, charging interface and protection requirements.

Integrating a 48V Battery Pack into Your Equipment

The mechanical and electrical interfaces can determine whether a proposed battery configuration is practical. An otherwise suitable 48V lithium battery pack may still require changes to its enclosure, cable routing or protection design before it can be installed in a finished product.

🔌Electrical Connections and Charging Interfaces

Connector choice should reflect the equipment’s current requirements, installation conditions and service needs. For an OEM design, define the discharge connector, charging connector, polarity, cable length and available routing space. The charger and the equipment must also be compatible with the battery management system and its protection settings.

📐Enclosure and Mounting Requirements

A battery compartment imposes limits on overall dimensions, connector position and access for installation or replacement. A pack built with 18650 cells may have a different mechanical arrangement from one using 21700 cells, even when their total capacities are similar. Drawings, mounting details and maximum permitted dimensions are therefore useful early in development.

🛡️Protection and Monitoring

Battery protection should be selected for the proposed cell arrangement and equipment load. Depending on the design, this may include overcharge, overdischarge, overcurrent, short-circuit and temperature protection, together with cell balancing. Where equipment requires battery status information or a communication interface, those functions should be specified during engineering review rather than assumed to be included in every pack.

Electric bicycle battery mounting for a 48V lithium-ion system — Frame-mounted battery on a commuter e-bike — illustrative OEM integration concept

48V Battery Packs for OEM Applications

Different 48V equipment platforms may have similar nominal voltage requirements but different expectations for battery packaging, charging and electrical interfaces.

🚲48V Battery Packs for E-Bikes

A 48V battery pack for ebike applications must match the bike’s controller voltage limits, battery input current and available mounting space. Capacity affects the energy available for riding, while the discharge rating determines whether the battery can support the controller’s operating demand. The enclosure and connectors also matter: frame-mounted, removable and enclosed battery arrangements can require different mechanical and electrical designs. For OEM projects, these details should be established before finalizing the cell configuration.

🚷Electric Scooters and Light Mobility Equipment

Electric scooters and other compact mobility devices may have restricted installation space and specific charging connections. Battery selection should take account of the required travel distance, controller specifications, mechanical protection and available mounting positions. A higher-capacity pack is useful only when its electrical ratings and physical structure remain compatible with the equipment.

🏪Industrial and Automated Equipment

Industrial equipment may use a 48V-class battery system where the installation space, electrical load and charging method are already defined. The battery arrangement may need to accommodate a particular enclosure, connector location, maintenance access or monitoring function. For these projects, the equipment specification is the starting point for determining whether a proposed pack configuration is suitable.

Custom 48V Lithium Battery Pack Design

For a custom 48V lithium battery pack, the goal is to turn equipment requirements into an agreed electrical and mechanical specification. YATTOX’s battery pack capabilities cover cell configuration, protection integration, wiring and assembly. Each project should identify the required interfaces and acceptance criteria before a final pack design is approved.

🔋Cell Arrangement and Capacity

The proposed 13S layout is developed around the target capacity, current demand and physical constraints. 18650 and 21700 cell formats may lead to different pack structures. The selected cell model must support the electrical requirements of the finished assembly.

⚙️BMS and Interface Design

The protection circuit should be matched to the series arrangement, charge and discharge limits and equipment operating conditions. Connector selection, wire specifications, temperature sensing and any requested monitoring interface should be considered together.

🔧Pack Construction and Inspection

Mechanical design may include cell positioning, insulation, enclosure arrangements, cable exits and mounting details. Electrical and assembly checks can be defined according to the final specification, including pack voltage, capacity, connections, protection behavior and dimensional requirements. Testing scope, applicable product documentation and shipment requirements should be confirmed as part of the project.

Information Needed for a 48V Battery Quote

To assess the proposed configuration, please provide:

Project Detail	Information to Share
Equipment	Application and operating conditions
Voltage	Permitted equipment input range
Capacity	Target Ah, Wh or operating time
Load	Continuous current and short-duration peaks
Charging	Charger voltage, current and connector
Mechanical design	Available dimensions and mounting layout
Connections	Discharge connector, cable and monitoring needs
Order planning	Expected quantity and project stage

An existing battery specification or installation drawing can help establish the technical requirements.

Request a 48V Battery Consultation →

Frequently Asked Questions About 48V Battery Packs

Q1: Why does a 48V lithium-ion battery pack charge to 54.6V?

Many 48V-class lithium-ion packs use thirteen conventional cells in series. With a maximum charge voltage of 4.2V per cell, the pack reaches 54.6V at full charge. Its nominal rating is approximately 48V, depending on the nominal voltage assigned to the selected cells. Equipment and chargers must be compatible with the complete battery specification.

Q2: What is the difference between a 48V Li-ion and a 48V LiFePO4 battery pack?

The two chemistries commonly use different cell arrangements and charging voltages. A typical 13S Li-ion pack has a nominal voltage of 48.1V and charges to 54.6V, while a common 16S LiFePO4 pack is rated at 51.2V and charges to 58.4V. They should not be treated as direct replacements without checking system compatibility.

Q3: How should I choose between a 48V 10Ah, 20Ah and 30Ah battery?

Start with the energy required for the intended operating time. A higher Ah rating provides more nominal energy at the same voltage, but also changes cell count and potentially the finished pack’s weight and dimensions. The chosen configuration must meet the equipment’s discharge current, installation and charging requirements. Nominal capacity alone is not sufficient.

Q4: Can a 48V lithium-ion battery pack replace a lead-acid battery?

Replacement may be possible, but a matching nominal voltage is not enough. The equipment’s allowable voltage range, charging method, current demand and battery compartment must be checked. The lead-acid charger may not be appropriate for the proposed lithium-ion pack, so a compatible charging arrangement may be required.

Q5: Can YATTOX customize the BMS, connectors and enclosure?

The required BMS functions, wiring, connectors and mechanical structure can be included in an OEM design review. Customers should specify the controller limits, charging arrangement, battery compartment dimensions and any monitoring requirements. Feasibility and final specifications depend on the selected components and the equipment’s operating conditions.

Q6: What should I provide before requesting OEM samples or a quotation?

Useful information includes the equipment type, permitted operating voltage, target capacity, continuous and peak battery current, charger details, available dimensions, connectors and expected order quantity. A drawing or existing battery datasheet is helpful. Sample scope, evaluation criteria, pricing and schedule can then be discussed against the proposed design.
